CAPABILITIES
|
Category |
Description |
Capability |
|
File Formats |
Gerber files- preferred |
Gerber file 274-X or ODB++ |
|
Drill file |
3.3 leading mm |
|
|
Size |
Max. finished PCB dimensions |
400mm x 1200mm – Single/ Double-sided |
|
600mm x 700mm – Multilayer |
||
|
Board Thickness |
Standard |
1.6mm ±10% |
|
Min. |
0.6mm ±10% |
|
|
Max. |
3.2mm ±10% |
|
|
Bow and twist |
0.50% |
|
|
Copper Thickness |
Outer Cu weight |
0.5oz-12oz |
|
Inner Cu weight |
0.5oz-12oz |
|
|
Laminate Materials |
FR4(KB, ILM, Shengyi, Huazheng new material ) ,High TG, Aluminum plate( Taiwan) |
|
|
Board Cutting |
Max. number of layers |
20 |
|
Min. thickness for inner layers (Cu thickness are excluded) |
0.05mm |
|
|
Drilling |
Min. size |
0.20mm |
|
Max. size |
6.00mm |
|
|
Drill Deviation |
±0.075mm |
|
|
NPTH hole tolerance |
±0.05mm |
|
|
Angle of Countersink |
45° |
|
|
PTH |
Min. hole size |
0.20mm |
|
Aspect ratio |
8:1 |
|
|
Etching |
Trace width tolerance |
±20% |
|
Min. trace width / space (1oz finished Cu weight |
75um/75um (3mil/3mil) |
|
|
Min. trace width / space (1oz finished Cu weight |
89um/89um (3.5mil/3.5mmil) |
|
|
Min. trace width / space (2oz finished Cu weight) |
150um/150um (6mil/6mil) |
|
|
Solder Mask |
Color |
Green,White,Black,Red,Blue,Etc. |
|
Min. solder mask clearance |
3mil |
|
|
Thickness |
Line angle:8um(min),Linear plane:10um(min), |
|
|
Silkscreen |
Color |
White,Black,Etc. |
|
Min. trace width |
100um 4mil |
|
|
Min. size |
0.7mm 28mil |
|
|
Test |
AOI |
100% |
|
Flying Probe Tester |
Sample 100% |
|
|
E-test |
Mass order 100% |
|
|
Controlled Impedance |
Tolerance |
+/-10% |
|
Impedance tester |
Test impedance module |
|
|
Profile |
Tolerance |
±0.10mm |
|
V—CUT Depth |
±0.10mm |
|
|
V—CUT angle deviation |
30° |
|
|
Semi-hole |
Minimum half hole:0.40mm |
|
|
Surface Finish |
HASL,Immersion gold(ENIG),OSP |
|
